Pulp Preparation & Sheet Forming Equipment

Paper Testing Instruments

Filter Paper & Media Testing Instruments

Tissue & Hygiene Product Testing Instruments

Molded Pulp & Paper Product Testing Instruments

Coating & Film Applicators

طريقة العرض

Pulp Molding Machine

The Pulp Molding Machine is a small-scale experimental device designed by Annimet for molding trials, using straw pulp, bagasse, wood pulp, reed pulp, and waste paper pulp as raw materials. Through pulping, vacuum forming, and hot-press drying processes, it manufactures paper products of specific shapes. The system consists of a slurry forming system, vacuum dewatering system, and wet hot-press forming system, featuring precise in-mold slurry injection and vacuum suction drainage. It is suitable...
إرسال الطلب
Softness Tester

The Softness Tester is developed according to GB/T 8942-2002, simulating hand feel for softness measurement. It is applicable to the softness determination of high-grade tissue paper, silk, nonwovens, textiles, leather, and other sheet-like flexible materials. With a range of 10-1000 mN and indication error ±1%, it features touchscreen control, bilingual (Chinese/English) interface, adjustable slit widths (5/6.35/10/20 mm), and multiple communication ports. It is a professional device for evalua...
إرسال الطلب
Digital Pore Size Tester

The Digital Pore Size Tester (Bubble Point Test Stand) is a filter media pore size analyzer designed in accordance with GB/T 2679.14-1996 and GB/T 1967-1996 standards. It measures the maximum pore size and average pore size of filter paper, glass fiber separators, textile materials, and various sintered materials. Equipped with touchscreen control, temperature compensation, and a built-in micro printer, it features a maximum pressure range of 15 kPa, pore size testing range of 5-500 μm, and disp...
إرسال الطلب
Digital Air Permeance Tester

The Digital Air Permeance Tester is a fully automatic multi-function instrument for paper and paperboard air permeance testing. Through modular design, it complies with multiple standards and test methods including Schober, Gurley, and Bendtsen. The flow range is 0-5000 ml/min, with an adjustable pressure range of 10 Pa-3 kPa, and a standard effective test area of 10.0±0.2 cm². It features automatic specimen clamping, touchscreen control, automatic reading and result judgment, and optional PC so...
إرسال الطلب
Digital Stiffness Tester

The Digital Stiffness Tester is a specialized instrument for measuring the bending resistance (stiffness) of paper and paperboard, designed according to the internationally accepted static bending method. The stiffness test angle is 15° (adjustable 1-90°), with a measuring range of 0-500 gf, display resolution of 0.001, and accuracy of 0.1% FS. It features a color touchscreen with multiple unit display options including gram, mN, LB, and OZ, and a test time adjustable from 1-90 s. It is suitable...
إرسال الطلب
Digital Internal Bond Tester

The Digital Internal Bond Tester is manufactured in accordance with TAPPI-UM403 and GB/T 26203-2010 standards, designed for testing the internal bond strength (ply bond) of paper and paperboard. It can test 5 groups of specimens simultaneously, with specimen dimensions of 25.4×25.4 mm, a measuring range of 1-1500 J/m², an impact angle of 90°, and angle accuracy of 0.01°. Featuring an imported sensor and magnetic positioning structure, it provides digital display with printable results in multipl...
إرسال الطلب
Automatic Smoothness Tester

The AT-QPH Automatic Smoothness Tester is an upgraded version of the AT-PH-1, operating on the Bekk principle for measuring paper and paperboard surface smoothness. It uses a pressure sensor to apply the standard 100±2 kPa pressure, replacing the traditional lever and weight mechanism. With a test area of 10±0.05 cm² and a measurement range of 1-99999 s in three auto-switching ranges, it features an imported oil-free vacuum pump for maintenance-free operation and a 7-inch color touchscreen for o...
إرسال الطلب
Paper Bursting Strength Tester

The Paper Bursting Strength Tester is designed for testing the bursting strength of paper and paperboard, conforming to ISO 2759, GB/T 6545-1998, and JJG (Light Industry) 61-2000 standards. The measuring range is 1-1600 kPa with a resolution of 0.11 kPa and an indication error of ±0.5% FS. It features pneumatic specimen clamping with adjustable clamping force ≥690 kPa and touchscreen operation. Using 201-50CS dimethyl silicone oil for hydraulic transmission with a pumping speed of 95±5 ml/min, i...
إرسال الطلب
Paper Tensile Strength Tester

The Paper Tensile Strength Tester is designed and manufactured according to GB/T 12914-2008, capable of testing tensile strength, tensile index, breaking length, elastic modulus, and other properties of paper and paperboard. With a standard range of 500 N (optional 30 N/50 N for tissue paper), speed range of 1-500 mm/min, and force accuracy of 0.01 N, it features a 7-inch touchscreen, automatic grip distance adjustment, built-in micro printer, force-displacement curves, and tabular auto-processi...
إرسال الطلب
Quantitative Sampler

The Quantitative Sampler is a precision circular specimen cutter designed and manufactured according to the QB/T 1671 standard. It cuts specimens with an area of 100 cm² and a cutting accuracy of ±0.35%, suitable for standard sample preparation for grammage testing of paper and paperboard. It features a one-piece cast iron structure and a special No. 10 steel wave-shaped blade with high-temperature quenching treatment for effortless cutting and long service life. The innovative pressing cap desi...
إرسال الطلب
Slot-Die Coating Tester

The AT-XTB-1000C Slot-Die Coating Tester, developed by Shandong Annimet Instrument, employs non-contact slot-die extrusion technology to precisely control wet film thickness through feed pressure, slot gap, and head-to-substrate clearance. It achieves wet films down to 1 μm and dry films at the nano-scale. Multiple platform options (granite, vacuum, die steel, glass) are available, and the advanced version features a height regulation and feedback system. It is widely used in organic photovoltai...
إرسال الطلب
Flatbed Coating Tester (High-Precision)

The AT-TB-2100 series is a high-precision laboratory flatbed coating device developed by Shandong Annimet, designed for trial coating, process development, and quality control of coatings, adhesives, hot melts, and conductive/nano materials on substrates like paper, nonwovens, mesh, glass, and metal foils. With adjustable speed of 1-2000 mm/min and an effective area of 300×400 mm, it offers optional vacuum adsorption and 200°C heated platform, touchscreen recipe management, and replaces manual d...
إرسال الطلب
Flatbed Coating Tester

The AT-TB-1100 series flatbed coating tester is a precision laboratory coating device developed by Shandong Annimet, designed for applying coatings, adhesives, hot melts, and conductive/nano materials onto substrates such as paper, nonwovens, glass, and metal foils. The coating speed is adjustable from 1-2000 mm/min, with an effective area of 300×400 mm. It supports multiple coating methods including doctor blade and wire bar, and offers options for a vacuum adsorption table and heated base plat...
إرسال الطلب
Film Transfer Sizer

The Film Transfer Sizer is an advanced laboratory sizing and coating device that uses a metering rod to pre-meter the size onto an applicator roll, which then transfers a uniform film to the paper sheet. The coating weight ranges from 0.5-12 g/m², with an effective width of 300 mm, a sizing plate of 330×420 mm, and temperature adjustable from RT to 100°C. It supports single or double-sided application, offering uniform film, high repeatability, and simple operation. It is ideal for surface sizin...
إرسال الطلب
Continuous Coating Tester

The Continuous Coating Tester is designed for roll-to-roll coating and laminating of web substrates. It supports both metering rod and knife coating methods, with an effective coating width of 280 mm and a mechanical speed of 0.2-2 m/min. Equipped with two drying ovens (30-120°C ±2°C), unwinding, winding, laminating traction, and electrical control systems, it handles paper (60-120 gsm) and film (0.03-0.15 mm) substrates using water-based or solvent-based coatings. It is a professional platform...
إرسال الطلب
Hot Melt Adhesive Coating Tester

The benchtop Hot Melt Adhesive Coating Tester is a compact device for hot melt coating and laminating as well as surface coating of various substrates. The glue tank is thermostatically heated from room temperature to 180°C, with a coating width of 300 mm, mechanical speed of 100-800 mm/min, and coating accuracy better than ±2 μm. Its aluminum alloy benchtop design is simple to operate, making it ideal for hot melt adhesive bench-scale R&D.
إرسال الطلب
Dip Coating Machine

The Dip Coating Machine is a laboratory benchtop device designed for impregnation and double-sided coating of flat substrates such as paper, carbon paper, and nonwoven fabrics. It employs a slot-type dip coating method with both automatic and manual coating modes, a coating width of 300 mm, and an adjustable speed range of 0.1-10 m/min. Pneumatic roller pressure is digitally adjustable, with a maximum pressure of 20 kN/cm. Compact in size and highly controllable, it is an ideal tool for process...
إرسال الطلب
Electric Digester

The Electric Digester is a laboratory device designed to simulate the operation of an industrial rotary digester, with the vessel rotating to ensure thorough mixing of raw materials and pulping liquor. It is suitable for sulfonation, acid, or alkaline cooking of raw materials in paper laboratories. With a capacity of 15 liters, operating pressure of 8 kg/cm², heating power of 4.5 kW, temperature measurement accuracy of ±0.1°C, and control accuracy of ±3°C, it features a 304/316L stainless steel...
إرسال الطلب
